Mounting system equipment
Installation & Configuration Manual
6.3.3 Installing the batteries
If using two batteries in the G5 housing, it is recommended that both batteries
should be the same Ah rating.
Optional expander positions
To install the batteries:
1. Place the batteries into the battery compartment.
2. Press the metal tabs at the top and either side of the batteries in towards the
batteries.
3. Secure each battery to the housing using a battery strap. Ensure that the strap
is thread through the battery strap holes at the back of the battery compartment
and around the battery, with the two ends of the strap at the front of the battery.
4. Fasten the two ends of the strap firmly using the Velcro strip. Ensure that the
strap is tight around the battery.
