Technical Data
4
SPC4000
31
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
4 Technical Data
4.1 SPC4000
Programmable areas
4
Max. number of user PINs
100
Remote controls
Up to 32
Wireless Panic Alarm
Up to 128
Event memory
1000 intrusion events, 1000 access events
Number of on-board zones
8
Max. number of hardwired zones
32
Max. number of wireless zones
32 (take away wired zones)
Max. number of Intrunet wireless detectors
per wireless receiver (recommended)
20
EOL resistor
Dual 4k7 (default), other resistor combinations
configurable
Number of on-board relays
1 strobe (30 VDC / 1 A resistive switching current)
Number of on-board open coll.
2 internal / external bell, 3 freely programmable (each
max. 400 mA resistive switching current, supplied via
auxiliary output)
Firmware
V3.x
Door capacity
Max. 4 entry doors or 2 entry/exit doors
Number of card reader
Max. 4
Radio module
 SPC4221: integrated SiWay RF receiver (868 MHz)
 SPC4320.220: Optional (SPCW111),
 SPC4320.320: Optional (SPCW110)
Verification
4 verification zones with max. 4 IP-cameras and 4 audio
devices.
Video
Up to 16 pre / 16 post event images (by JPEG resolution
320 x 240, max. 1 frame / sec.)
Audio
Up to 60 sec. pre / 60 sec. post audio recording
Field bus 1)
X-BUS on RS-485 (307 kb/s)
Number of field devices 2)
Max. 11 (4 keypads, 2 door-expanders, 5 input/output
expanders)
Connectable field devices
 Keypads: SPCK42x, SPCK62x
 Door expanders: SPCA210, SPCP43x
 Expanders with I/O: SPCE65x, SPCE45x,
SPCP33x, SPCE110, SPCE120, SPCV32x
Interfaces
 1 X-BUS (1 spur)
 1 RS232
 USB (PC connection)
 1 SPC Fast Programmer
 SPC43xx: Additionally 1 Ethernet (RJ45)
Tamper contact
Front spring tamper, 2 auxiliary tamper contact inputs
Power supply
Type A (per EN50131-1)
Mains voltage
230 VAC, + 10%/ -15%, 50 Hz
Mains fuse
250 mA T (replaceable part on mains terminal block)
Power consumption
SPC42xx: Max. 160 mA at 230 VAC
SPC43xx: Max. 200 mA at 230 VAC
Operating current
SPC42xx Controller: Max. 160 mA at 12 VDC
SPC43xx Controller: Max. 200 mA at 12 VDC
