Engineer programming via the browser
Installation & Configuration Manual
17.6.3.1 Log - Wireless sensor X
To view a quick log of events for a wireless sensor:
1. Click the Log button.
2. See table below for further information.
3. Create a text file of the log by clicking Text File.
The date and time of the logged event.
The wireless receiver location, i.e. wireless module mounted on the keypad,
controller or wireless expander.
The signal strength received from the sensor (01=low, 09=high).
The physical status of the sensor.
The status of the battery connected to the sensor (OK, Fault).
17.6.4 Zones
For configuration see page [âž™ 237].
1. To view all zones, select Status > Inputs > All Zones. To view X-Bus only
zones, select the X-Bus Zones tab or to view wireless zones only, select the
Wireless Zones tab.
2. See tables below for further information.
