Vanderbilt SPC53 Series User Manual

4
Technical Data
SPC5000
32
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
Quiescent current
SPC42xx Controller:
Max. 140 mA at 12 VDC (165 mA with PSTN, 270 mA
with GSM, 295 mA with PSTN & GSM)
SPC43xx Controller:
Max. 170 mA at 12 VDC (195 mA with PSTN, 300 mA
with GSM, 325 mA with PSTN & GSM)
Output voltage
13-14 VDC in normal conditions (mains powered and
fully charged battery), min. 10.5 VDC when powered by
secondary device (before system shut down to battery
deep discharge protection)
Low voltage trigger
7.5 VDC
Overvoltage protection
15.7 VDC
Peak to Peak ripple
Max. 5 % of output voltage
Auxiliary power (nominal)
Max. 750 mA at 12 VDC
Battery type
SPC422x/4320: YUASA NP7-12FR (7 Ah), Battery not
supplied
Battery charger
SPC422x/4320: Max. 72h to 80% of battery capacity
Battery protection
Current limited to 1 A (fuse protected), deep discharge
protection at 10.5 VDC +/- 3 %
Software update
Local and remote upgrade for controller, peripherals and
GSM/PTSN modems.
Calibration
No calibration checks required (calibrated at
manufacturing)
Serviceable parts
No serviceable parts
Operating temperature
-10 ~ +50 °C
Relative humidity
Max. 90 % (non condensing)
Colour
RAL 9003 (signal white)
Weight
SPC422x/4320: 4.500 kg
Dimensions (W x H x D)
SPC422x/4320: 264 x 357 x 81 mm
Housing
SPC4320.320: Small metal housing (1.2 mm mild steel)
SPC422x.220: Small housing with metal base (1.2 mm
mild steel) and plastic lid
Housing can contain up to
SPC422x/4320: 1 additional expander (size 150 mm x 82
mm)
IP rating
30
ATS
2
ATP
4
Event Profiles
5
Event Exceptions
10
Command Profiles
5
1) Max. 400 m between devices / cable types IYSTY 2 x 2 x Ø 0.6 mm (min.), UTP
cat5 (solid core) or Belden 9829.
2) More I/O expanders can be addressed instead of a keypad or door expander,
but number of programmable inputs / outputs cannot exceed specified system
limits.
4.2 SPC5000
Programmable areas
16
Max. number of user PINs
500
Remote controls
Up to 100
Wireless Panic Alarm
Up to 128
