Engineer programming via the browser
Installation & Configuration Manual
Performable actions
Updates the status information displayed for the panel.
Click on the Log button to view a log of the input status of that zone.
Click this button to inhibit a fault or open zone. The inhibit operation will
disable that fault or zone for one arming period only.
Inhibit operation is not available in Security Grade EN 50131 Grade 3.
Click this button to restore the alarm condition of the panel.
Zone . Isolating a zone will deactivate that zone until such time as the zone
is explicitly deisolated again.
It is recommended that you exercise caution when isolating zones as those
zones will not be active every time the system is SET.
Highlight a zone and click this button to perform a Soak test on that zone.
Click this button to initiate a test of the selected seismic sensor. For more
information on seismic sensors, see Seismic Sensors [âž™ 324].
Click this button to hide all closed inputs.
Select a zone type from the dropdown menu. Only the summary of this zone
type will be displayed.
17.6.5 Doors
1. Select Status > Doors.
2. See tables below for further information.
This ID number is a unique identifier for the door.
The zone number the door position sensor is attached to (only if the door position
sensor input is also used as intrusion zone).
The area the door position sensor input and the card reader are assigned to.
Status of the door position sensor.
Status of the door release switch.
The status of the door (OK, fault).
Specifies the door operate mode.
Performable actions
Updates the door summary.
Displays a log of events for the selected door.
Unlocks the selected door.
Returns the door to normal system control.
Unlocks the door for one timed interval.
