Mounting system equipment
Installation & Configuration Manual
Battery temperature leads
Optional expander positions
Two batteries, with a maximum capacity of 27 Ah, can be accommodated in the
battery compartment at the bottom of the housing.
An optional external antenna must be fitted to a metallic housing if wireless
functionality is required. Knockout holes are available in three positions on the top
of the housing where the antenna can be installed. If an antenna is fitted to the
unit, it must be enabled in the firmware.
The SPC G5 housing provides 4 screw holes for wall mounting the unit.
