TRANSMISSION
M6040, M7040, WSM
3-S2
4WD CLUTCH
9Y1210143TRS0001US0
Symptom Probable Cause Solution
Reference
Page
4WD Clutch Slip Operating pressure is low Adjust 3-S13
4WD solenoid valve malfunctioning Repair or replace 3-S16
Clutch disc or drive plate excessively worn Replace 3-S42,
3-S43
Deformation of piston or return plate Replace 3-S42,
3-S43
Front Wheel Does
Not Rotate
4WD clutch malfunctioning Repair or replace 3-S42
4WD propeller shaft coupling disengaged Engage –
4WD switch defective Engage 9-S33
4WD Operating
Pressure Is Low
Transmission oil improper or insufficient Replenish or change G-10
Relief valve malfunctioning Adjust or replace 3-S13
KiSC issued 07, 2012 A
