CABIN
M6040, M7040, WSM
10-S41
Dismounting Cabin
1. Remove the cabin mounting all screws and nut (1).
2. Set the cabin dismounting tool (2) to the cabin.
3. Dismounting the cabin from tractor body.
(When reassembling)
9Y1210143CAS0068US0
Tightening torque
Cabin mounting screw and
nut
124 to 147 N·m
12.6 to 15.0 kgf·m
91.2 to 108 lbf·ft
(1) Cabin Mounting Nut (2) Cabin Dismounting Tool
