User's Manual 1190 Document #: LTRT-10632
Mediant 800B Gateway & E-SBC
Parameter Description
When the parameter is enabled, the device sends the Caller ID
number (calling number) with the cpc code (received in the SIP
INVITE message) to the device's FXS port. The cpc code is
added as a prefix to the caller ID (after IP-to-Tel calling number
manipulation). For example, assuming that the incoming INVITE
contains the following From (or P-Asserted-Id) header:
From:<sip:+551137077801;cpc=payphone@10.20.7.35>;t
ag=53700
The calling number manipulation removes "+55" (leaving 10
digits), and then adds the prefix 7, the cpc code for payphone
user. Therefore, the Caller ID number that is sent to the FXS
port, in this example is 71137077801.
If the incoming INVITE message doesn't contain the 'cpc'
parameter, nothing is added to the Caller ID number.
CPC Value in
Received INVITE
CPC Code Prefixed
to Caller ID (Sent to
FXS Endpoint)
Description
cpc=unknown 1 Unknown user
cpc=subscribe 1 -
cpc=ordinary 1 Ordinary user
cpc=priority 2 Pre-paid user
cpc=test 3 Test user
cpc=operator 5 Operator
cpc=data 6 Data call
cpc=payphone 7 Payphone user
Note:
 The parameter is applicable only to FXS interfaces.
 For the parameter to be enabled, you must also set the
parameter EnableCallingPartyCategory to 1.
[EnableCallerIDTypeTwo] Disables the generation of Caller ID type 2 when the phone is
off-hooked. Caller ID type 2 (also known as off-hook Caller ID) is
sent to a currently busy telephone to display the caller ID of the
waiting call.
 [0] = Caller ID type 2 isn't played.
 [1] = (Default) Caller ID type 2 is played.
Note: The parameter is applicable only to FXS interfaces.
configure voip > interface fxs-fxo >
caller-id-timing-mode
[AnalogCallerIDTimingMode]
Determines when Caller ID is generated.
 [0] = (Default) Caller ID is generated between the first two
rings.
 [1] = The device attempts to find an optimized timing to
generate the Caller ID according to the selected Caller ID
type.
Note:
 The parameter is applicable only to FXS interfaces.
 If the parameter is set to 1 and used with distinctive ringing,
