C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 88 –
Auto Traffic Control Sets thresholds for broadcast and multicast storms which can be
used to trigger configured rate limits or to shut down a port
229
Configure Global Sets the time to apply the control response after traffic has
exceeded the upper threshold, and the time to release the control
response after traffic has fallen beneath the lower threshold
233
Configure Interface Sets the storm control mode (broadcast or multicast), the traffic
thresholds, the control response, to automatically release a
response of rate limiting, or to send related SNMP trap messages
235
Priority 239
Default Priority Sets the default priority for each port or trunk 239
Queue Sets queue mode for the switch; sets the service weight for each
queue that will use a weighted or hybrid mode
240
Trust Mode Selects IP Precedence, DSCP or CoS priority processing 246
DSCP to DSCP 247
Add Maps DSCP values in incoming packets to per-hop behavior and
drop precedence values for internal priority processing
247
Show Shows the DSCP to DSCP mapping list 247
CoS to DSCP 249
Add Maps CoS/CFI values in incoming packets to per-hop behavior and
drop precedence values for priority processing
249
Show Shows the CoS to DSCP mapping list 249
PHB to Queue 243
Add Maps internal per-hop behavior values to hardware queues 243
Show Shows the PHB to Queue mapping list 243
DiffServ 245
Configure Class 246
Add Creates a class map for a type of traffic 246
Show Shows configured class maps 246
Modify Modifies the name of a class map 246
Add Rule Configures the criteria used to classify ingress traffic 246
Show Rule Shows the traffic classification rules for a class map 246
Configure Policy 249
Add Creates a policy map to apply to multiple interfaces 249
Show Shows configured policy maps 249
Modify Modifies the name of a policy map 249
Add Rule Sets the boundary parameters used for monitoring inbound traffic,
and the action to take for conforming and non-conforming traffic
249
Show Rule Shows the rules used to enforce bandwidth policing for a policy
map
249
Configure Interface Applies a policy map to an ingress port 259
Table 6: Switch Main Menu (Continued)
Menu Description Page
