C
HAPTER
33
| VLAN Commands
Configuring Port-based Traffic Segmentation
– 840 –
show dot1q-tunnel This command displays information about QinQ tunnel ports.
COMMAND MODE
Privileged Exec
EXAMPLE
Console(config)#dot1q-tunnel system-tunnel-control
Console(config)#interface ethernet 1/1
Console(config-if)#switchport dot1q-tunnel mode access
Console(config-if)#interface ethernet 1/2
Console(config-if)#switchport dot1q-tunnel mode uplink
Console(config-if)#end
Console#show dot1q-tunnel
Current double-tagged status of the system is Enabled
The dot1q-tunnel mode of the set interface 1/1 is Access mode, TPID is 0x8100.
The dot1q-tunnel mode of the set interface 1/2 is Uplink mode, TPID is 0x8100.
The dot1q-tunnel mode of the set interface 1/3 is Normal mode, TPID is 0x8100.
.
.
.
RELATED COMMANDS
switchport dot1q-tunnel mode (838)
CONFIGURING PORT-BASED TRAFFIC SEGMENTATION
If tighter security is required for passing traffic from different clients
through downlink ports on the local network and over uplink ports to the
service provider, port-based traffic segmentation can be used to isolate
traffic for individual clients.
traffic-segmentation This command enables traffic segmentation globally, or configures the
uplink and down-link ports for a segmented group of ports. Use the no
form to disable traffic segmentation globally.
SYNTAX
[no] traffic-segmentation [uplink interface-list
downlink interface-list]
uplink – Specifies an uplink interface.
downlink – Specifies a downlink interface.
interface-list – One or more ports. Use a hyphen to indicate a
consecutive list of ports or a comma between non-consecutive ports.
Table 114: Commands for Configuring Traffic Segmentation
Command Function Mode
traffic-segmentation Enables and configures traffic segmentation GC
show traffic-segmentation Displays the configured traffic segments PE
