HAPTER

| Security Measures

Access Control Lists

– 320 –

WEB INTERFACE

To configure the name and type of an ACL:

1. Click Security, ACL.

2. Select Configure ACL from the Step list.

3. Select Add from the Action list.

4. Fill in the ACL Name field, and select the ACL type.

5. Click Apply.

Figure 172: Creating an ACL

To show a list of ACLs:

1. Click Security, ACL.

2. Select Configure ACL from the Step list.

3. Select Show from the Action list.

Figure 173: Showing a List of ACLs

CONFIGURING A

STANDARD IPV4 ACL

Use the Security > ACL (Configure ACL - Add Rule - IP Standard) page to

configure a Standard IPv4 ACL.

CLI REFERENCES

◆ "permit, deny, redirect-to (Standard IP ACL)" on page 713

◆ "show ip access-list" on page 718

◆ "Time Range" on page 572
