HAPTER

| Spanning Tree Commands

– 820 –

show spanning-tree

mst configuration

This command shows the configuration of the multiple spanning tree.

COMMAND MODE

Privileged Exec

EXAMPLE

Console#show spanning-tree mst configuration

Mstp Configuration Information

--------------------------------------------------------------

Configuration Name : R&D

Revision Level :0

Instance VLANs

--------------------------------------------------------------

0 1-4093

Console#
