C
HAPTER
11
| Quality of Service
Attaching a Policy Map to a Port
– 267 –
ATTACHING A POLICY MAP TO A PORT
Use the Traffic > DiffServ (Configure Interface) page to bind a policy map
to an ingress port.
CLI REFERENCES
â—† "Quality of Service Commands" on page 869
COMMAND USAGE
â—† First define a class map, define a policy map, and then bind the service
policy to the required interface.
â—† Only one policy map can be bound to an interface.
â—† The switch does not allow a policy map to be bound to an interface for
egress traffic.
PARAMETERS
These parameters are displayed:
◆ Port – Specifies a port.
◆ Ingress – Applies the selected rule to ingress traffic.
WEB INTERFACE
To bind a policy map to a port:
1. Click Traffic, DiffServ.
2. Select Configure Interface from the Step list.
3. Check the box under the Ingress field to enable a policy map for a port.
4. Select a policy map from the scroll-down box.
5. Click Apply.
Figure 132: Attaching a Policy Map to a Port
