C
HAPTER
5
| Interface Configuration
Saving Power
– 159 –
2. Select Add from the Action List.
3. Specify the source trunk.
4. Specify the monitor port.
5. Specify the traffic type to be mirrored.
6. Click Apply.
Figure 53: Configuring Trunk Mirroring
To display the configured mirror sessions:
1. Click Interface, Trunk, Mirror.
2. Select Show from the Action List.
Figure 54: Displaying Trunk Mirror Sessions
SAVING POWER
Use the Interface > Green Ethernet page to enable power savings mode on
the selected port.
CLI REFERENCES
â—† "power-save" on page 747
â—† "show power-save" on page 748
COMMAND USAGE
â—† IEEE 802.3 defines the Ethernet standard and subsequent power
requirements based on cable connections operating at 100 meters.
