| Automatic Traffic Control Commands

ATC Display Commands

– 787 –

EXAMPLE

Console#show auto-traffic-control interface ethernet 1/1

Eth 1/1 Information

------------------------------------------------------------------------

Storm Control: Broadcast Multicast

State: Disabled Disabled

Action: rate-control rate-control

Auto Release Control: Disabled Disabled

Alarm Fire Threshold(Kpps): 128 128

Alarm Clear Threshold(Kpps):128 128

Trap Storm Fire: Disabled Disabled

Trap Storm Clear: Disabled Disabled

Trap Traffic Apply: Disabled Disabled

Trap Traffic Release: Disabled Disabled

Console#
