C
HAPTER
33
| VLAN Commands
Configuring VLAN Interfaces
– 830 –
EXAMPLE
The following example shows how to set the interface configuration mode
to VLAN 1, and then assign an IP address to the VLAN:
Console(config)#interface vlan 1
Console(config-if)#ip address 192.168.1.254 255.255.255.0
Console(config-if)#
RELATED COMMANDS
shutdown (736)
interface (730)
vlan (828)
switchport
acceptable-frame-
types
This command configures the acceptable frame types for a port. Use the
no form to restore the default.
SYNTAX
switchport acceptable-frame-types {all | tagged}
no switchport acceptable-frame-types
all - The port accepts all frames, tagged or untagged.
tagged - The port only receives tagged frames.
DEFAULT SETTING
All frame types
COMMAND MODE
Interface Configuration (Ethernet, Port Channel)
COMMAND USAGE
When set to receive all frame types, any received frames that are untagged
are assigned to the default VLAN.
EXAMPLE
The following example shows how to restrict the traffic received on port 1
to tagged frames:
Console(config)#interface ethernet 1/1
Console(config-if)#switchport acceptable-frame-types tagged
Console(config-if)#
RELATED COMMANDS
switchport mode (832)
