C
HAPTER
28
| Port Mirroring Commands
RSPAN Mirroring Commands
– 769 –
COMMAND MODE
Global Configuration
COMMAND USAGE
The no rspan session command must be used to disable an RSPAN VLAN
before it can be deleted from the VLAN database (see the vlan command).
EXAMPLE
Console(config)#no rspan session 1
Console(config)#
show rspan Use this command to displays the configuration settings for an RSPAN
session.
SYNTAX
show rspan session [session-id]
session-id – A number identifying this RSPAN session. (Range: 1-2)
Only two mirror sessions are allowed, including both local and
remote mirroring. If local mirroring is enabled with the port monitor
command, then there is only one session available for RSPAN.
COMMAND MODE
Privileged Exec
EXAMPLE
Console#show rspan session
RSPAN Session ID : 1
Source Ports (mirrored ports) : None
RX Only : None
TX Only : None
BOTH : None
Destination Port (monitor port) : Eth 1/2
Destination Tagged Mode : Untagged
Switch Role : Destination
RSPAN VLAN : 2
RSPAN Uplink Ports : Eth 1/3
Operation Status : Up
Console#
