C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 92 –
Remote Configures the logging of messages to a remote logging process 372
SMTP Sends an SMTP client message to a participating server 373
Configure Server Configures a list of recipient SMTP servers 373
Add Adds a recipient SMTP server 373
Show Shows configured SMTP servers 373
Configure General Sets SMTP status, e-mail source and destination addresses 373
LLDP 376
Configure Global Configures global LLDP timing parameters 376
Configure Interface
Configure General Sets the message transmission mode, enables SNMP notification,
and sets the LLDP attributes to advertise
378
Add CA-Type Specifies the location of the device attached to an interface 382
Show CA-Type Shows the location of the device attached to an interface 382
Modify CA-Type Modifies the location of the device attached to an interface 382
Show Local Device Information 384
General Displays general information about the local device 384
Port/Trunk Displays information about each interface 384
Show Remote Device Information 387
Port/Trunk Displays information about a remote device connected to a port on
this switch
387
Port/Trunk Details Displays detailed information about a remote device connected to
this switch
387
Show Device Statistics 392
General Displays statistics for all connected remote devices 392
Port/Trunk Displays statistics for remote devices on a selected port or trunk 392
PoE Power over Ethernet 393
Configure Global Displays the power budget for the switch 394
Configure Interface Configures port power parameters 395
SNMP Simple Network Management Protocol 397
Configure Global Enables SNMP agent status, and sets related trap functions 399
Configure Engine 400
Set Engine ID Sets the SNMP v3 engine ID on this switch 400
Add Remote Engine Sets the SNMP v3 engine ID for a remote device 401
Show Remote Engine Shows configured engine ID for remote devices 401
Table 6: Switch Main Menu (Continued)
Menu Description Page
