C HAPTER 4 | Configuring the Switch
Access Control Lists
– 120 –
WEB INTERFACE
To configure rate limits which can be applied to a port:
1. Click Configuration, ACL, Rate Limiters.
2. For any of the rate limiters, select the maximum ingress rate that will
be supported on a port once a match has been found in an assigned
ACL.
3. Click Save.
Figure 31: ACL Rate Limiter Configuration
CONFIGURING ACCESS
CONTROL LISTS
The Access Control List Configuration page is used to define filtering rules
for an ACL policy, for a specific port, or for all ports. Rules applied to a port
take effect immediately, while those defined for a policy must be mapped
to one or more ports using the ACL Ports Configuration menu (page 118).
USAGE GUIDELINES
◆ Rules within an ACL are checked in the configured order, from top to
bottom. A packet will be accepted as soon as it matches a permit rule,
or dropped as soon as it matches a deny rule. If no rules match, the
frame is accepted.
◆ The maximum number of ACL rules that can be configured on the
switch is 128.
