C
HAPTER
4
| Configuring the Switch
Access Control Lists
– 122 –
The following buttons are used to edit or move the ACL entry (ACE):
ACE CONFIGURATION
Ingress Port and Frame Type
â—† Ingress Port - Any port, port identifier, or policy. (Options: Any port,
Port 1-28, Policy 1-8; Default: Any)
â—† Frame Type - The type of frame to match. (Options: Any, Ethernet,
ARP, IPv4; Default: Any)
Filter Criteria Based on Selected Frame Type
â—† Any frame type:
MAC Parameters
â–
DMAC Filter - The type of destination MAC address. (Options: Any,
MC - multicast, BC - broadcast, UC - unicast; Default: Any)
â—† Ethernet:
MAC Parameters
â–
SMAC Filter - The type of source MAC address. (Options: Any, MC -
multicast, BC - broadcast, UC - unicast, Specific - user defined;
Default: Any)
â–
DMAC Filter - The type of destination MAC address. (Options: Any,
MC - multicast, BC - broadcast, UC - unicast, Specific - user
defined; Default: Any)
Ethernet Type Parameters
â–
EtherType Filter - This option can only be used to filter Ethernet II
formatted packets. (Options: Any, Specific (600-ffff hex);
Default: Any)
Table 11: QCE Modification Buttons
Button Description
Inserts a new ACE before the current row.
Edits the ACE.
Moves the ACE up the list.
Moves the ACE down the list.
Deletes the ACE.
The lowest plus sign adds a new entry at the bottom of the list.
