C
HAPTER
5
| Monitoring the Switch
Displaying the MAC Address Table
– 181 –
WEB INTERFACE
To display DHCP relay statistics, click Monitor, DHCP, Relay Statistics.
Figure 63: DHCP Relay Statistics
DISPLAYING THE MAC ADDRESS TABLE
Use the MAC Address Table to display dynamic and static address entries
associated with the CPU and each port.
PARAMETERS
These parameters are displayed on the MAC Address Table:
Start from VLAN # and MAC address # with # entries per page -
These input fields allow you to select the starting point in the table.
Type - Indicates whether the entry is static or dynamic. Dynamic MAC
addresses are learned by monitoring the source address for traffic
entering the switch. To configure static addresses, refer to “Configuring
the MAC Address Table” on page 99.
VLAN - The VLAN containing this entry.
MAC Address - Physical address associated with this interface.
Port Members - The ports associated with this entry.
