C
HAPTER
4
| Configuring the Switch
IGMP Snooping
– 90 –
PARAMETERS
The following parameters are displayed on the SSH Configuration page:
◆ Mode - Allows you to enable/disable SSH service on the switch.
(Default: Disabled)
WEB INTERFACE
To configure SSH:
1. Click Configuration, SSH.
2. Enable SSH if required.
3. Click Save.
Figure 16: SSH Configuration
IGMP SNOOPING
Multicasting is used to support real-time applications such as
videoconferencing or streaming audio. A multicast server does not have to
establish a separate connection with each client. It merely broadcasts its
service to the network, and any hosts that want to receive the multicast
register with their local multicast switch/router. Although this approach
reduces the network overhead required by a multicast server, the
broadcast traffic must be carefully pruned at every multicast switch/router
it passes through to ensure that traffic is only passed on to the hosts which
subscribed to this service.
This switch can use Internet Group Management Protocol (IGMP) to filter
multicast traffic. IGMP Snooping can be used to passively monitor or
“snoop” on exchanges between attached hosts and an IGMP-enabled
device, most commonly a multicast router. In this way, the switch can
discover the ports that want to join a multicast group, and set its filters
accordingly.
If there is no multicast router attached to the local subnet, multicast traffic
and query messages may not be received by the switch. In this case (Layer
2) IGMP Query can be used to actively ask the attached hosts if they want
to receive a specific multicast service. IGMP Query thereby identifies the
