Edge-Core ES4528V-38 User Manual

A PPENDIX B | Troubleshooting
Using System Logs
– 382 –
USING SYSTEM LOGS
If a fault does occur, refer to the Installation Guide to ensure that the
problem you encountered is actually caused by the switch. If the problem
appears to be caused by the switch, follow these steps:
1. Enable logging.
2. Set the error messages reported to include all categories.
3. Enable SNMP.
4. Enable SNMP traps.
5. Designate the SNMP host that is to receive the error messages.
6. Repeat the sequence of commands or other actions that lead up to the
error.
7. Make a list of the commands or circumstances that led to the fault. Also
make a list of any error messages displayed.
8. Contact your distributor’s service engineer.
For example:
>system log
>system log all
>snmp mode enable
>snmp trap mode enable
>snmp trap destination 192.168.1.23
.
.
.

Edge-Core ES4528V-38 Specifications

General

Uplink Ports	4 x 1G/10G SFP+
Switching Capacity	128 Gbps
MAC Address Table Size	16K
VLANs	4K
Ports	24 x 10/100/1000BASE-T
Forwarding Rate	95.2 Mpps
Jumbo Frames	9K Bytes
Management	CLI, Web, SNMP
Power Supply	100~240VAC, 50-60Hz, Internal
Operating Temperature	0°C to 50°C (32°F to 122°F)
Dimensions (W x D x H)	440 x 44 mm
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Model	Edge-Core ES4528V-38
