– 35 –
2 INITIAL SWITCH CONFIGURATION
This chapter includes information on connecting to the switch and basic
configuration procedures.
CONNECTING TO THE SWITCH
The switch includes a built-in network management agent. The agent
offers a variety of management options, including SNMP, RMON and a web-
based interface. A PC may also be connected directly to the switch for
configuration and monitoring via a command line interface (CLI).
N
OTE
:
An IPv4 address for this switch is obtained via DHCP by default. To
change this address, see “Setting an IP Address” on page 38.
If the switch does not receive a response from a DHCP server, it will default
to the IP address 192.168.2.10 and subnet mask 255.255.255.0.
CONFIGURATION
OPTIONS
The switch’s HTTP web agent allows you to configure switch parameters,
monitor port connections, and display statistics using a standard web
browser such as Internet Explorer 5.x or above, Netscape 6.2 or above,
and Mozilla Firefox 2.0.0.0 or above. The switch’s web management
interface can be accessed from any computer attached to the network.
The CLI program can be accessed by a direct connection to the RS-232
serial console port on the switch, or remotely by a Telnet connection over
the network.
The switch’s management agent also supports SNMP (Simple Network
Management Protocol). This SNMP agent permits the switch to be managed
from any system in the network using network management software such
as HP OpenView.
The switch’s web interface, console interface, and SNMP agent allow you to
perform the following management functions:
◆ Set the administrator password
◆ Set an IP interface for a management VLAN
◆ Configure SNMP parameters
◆ Enable/disable any port
