C
HAPTER
5
| Monitoring the Switch
Displaying Information About Ports
– 153 –
DISPLAYING QOS
STATISTICS
Use the QoS Statistics page to display the number of packets processed by
each service queue.
PARAMETERS
These parameters are displayed on the Queuing Counters page:
◆ Low Queue Receive/Transmit – The number of packets received and
transmitted through the low-priority queue.
◆ Normal Queue Receive/Transmit – The number of packets received
and transmitted through the normal-priority queue.
◆ Medium Queue Receive/Transmit – The number of packets received
and transmitted through the medium-priority queue.
◆ High Queue Receive/Transmit – The number of packets received
and transmitted through the high-priority queue.
WEB INTERFACE
To display the queue counters, click Monitor, Ports, QoS Statistics.
Figure 48: Queuing Counters
