Edge-Core ES4528V-38 User Manual

C HAPTER 12 | Port Commands
– 238 –
Enabling power saving mode can significantly reduce power used for cable
lengths of 20 meters or less, and continue to ensure signal integrity.
EXAMPLE
This example indicates that power usage for port 5 is 41% of normal.
Port>power 5 enable
Port>power 5
Port Power Usage
---- -------- -----
5 Enabled 41 %
Port>
port excessive This command displays or sets the response to take when excessive
transmit collisions are detected on a port.
SYNTAX
port excessive [port-list] [discard | restart]
port-list - A specific port or a range of ports. (Range: 1-28, or all)
discard - Discards a frame after 16 collisions.
restart - Restarts the backoff algorithm after 16 collisions.
DEFAULT SETTING
Discard
EXAMPLE
Port>excessive 5 restart
Port>

Edge-Core ES4528V-38 Specifications

General

Uplink Ports	4 x 1G/10G SFP+
Switching Capacity	128 Gbps
MAC Address Table Size	16K
VLANs	4K
Ports	24 x 10/100/1000BASE-T
Forwarding Rate	95.2 Mpps
Jumbo Frames	9K Bytes
Management	CLI, Web, SNMP
Power Supply	100~240VAC, 50-60Hz, Internal
Operating Temperature	0°C to 50°C (32°F to 122°F)
Dimensions (W x D x H)	440 x 44 mm
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Model	Edge-Core ES4528V-38
