E. Display after deleting the user fixed waypoint:
ID [1L]: Waypoint identifier (5 characters max.). Entry of an identifier will display all the parameters of that
waypoint. In the case of multiple waypoints with the same identifier, the SELECT WPT page will be displayed
for specification. Pressing this key with an empty scratchpad copies the identifier to the scratchpad. To delete a
user waypoint, press CLR to get the DELETE message and select identifier LSK key. Entry of an invalid
identifier will cause the advisory !NOT IN DATABASE message to appear. If a modification is in progress,
entering a new identifier will automatically cancel the deletion, as applicable.
WPT POS [1R]: Display of waypoint position. Pressing this key with an empty scratchpad copies the position to
the scratchpad.
BRG/DIS [1R]: Bearing and distance from the current aircraft position to the waypoint. The values will be
recomputed and displayed at a minimum rate of once every second.
NAME (2L),(2R): Airport waypoint names, 24 characters max.
DATABASE (2L),(2R): Display of the database containing the waypoint. Possible values are NAVIGATION,
CUSTOM, USER, and TEMPORARY.
REGION (3L), (3R) lower line: Display of REGION and ICAO code.
Complete list of region codes:
AFR: Africa MES: Middle East/South Asia
CAN: Canada PAC: Pacific
EEU: Eastern Europe SAM: South America
EUR: Europe SPA: South Pacific
LAM: Latin America USA: United States of America
CUS: Specific to customer
Sample ICAO country codes (2 characters):
EH= Europe, Netherlands EG= Europe, UK
NAV DATA 1/1
FVRD WPT POS
N03
o
21.12 W123
o
25.56
BRG/DIS 134
T
/123NM
DATABASE USER
REGION CAN CY
TYPE/CLASS TACAN/C/H
ELEVATION +2309
FT
CHAN 126X
DECLIN W116
o
<CANCEL DELETE? CONFIRM>
To Next Page
