OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Page A-70
August 17, 2010
RTE x LEGS 1/X
The RTE x LEGS page is used to display and modify the active flight plan. Waypoints can be created, inserted
and deleted. A holding pattern can be defined on any waypoint. Waypoints can be converted from fly-by (with
turn anticipation) to fly-over (no turn anticipation). The illustrations below demonstrate the different display
formats this page may have depending on the function being performed.
Display ACT RTE LEGS 1/X page by pressing [LEGS].
A. Normal ACTIVE format:
B. Active route with Route Discontinuity:
ACT RTE 1 LEGS 1/2
264
o
12.8NM
JOH /H
262
o
113NM
D173J 280/1600A
263
o
RARCANC 10.6NM
D233J 1600A
053
o
CRS 10.0NM
ANC FAF
053
o
CRS 5.09NM
RW06R /OMAP
<RTE 2 LEGS LEGS ETA>
ACT RTE 1 LEGS 2/2
299
o
39.6NM
N51W125 300-320
298
o
154NM
YZP FL350B
320
o
45.0NM
YZP01
THEN
-- ROUTE DISCONTINUITY -
KILLA
LEGS ETA>
