OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Page A-96
August 17, 2010
VOR/DME STATUS 1/1 Page (if VOR, DME interfaces are configured)
The VOR/DME page displays the VOR and DME sensor inputs used in FMS radial/distance radio navigator and
the resulting position fix.
Display VOR/DME STATUS 1/1 page by pressing [INIT REF], <NAV STATUS>, and <VORDME>.
NOTE: The title will change to VOR/DME, as applicable, if some of the equipment is not configured.
A. Single VOR and DME configuration:
B. Dual VOR, single DME (configured as "single", "single_1" or "single_2"):
1R
2R
3R
4R
5R
6R
VOR/DM
E
STATUS 1/1
SOURCE/ID FREQ RAD/DME
VOR1
YJN 115.80 260°
DME YJN 115.80 130
NM
VOR2 YUL 116.30 180°
DME IABC 109.30 12.0
NM
POSITION
N45°00.00
W072°00.00
<NAV STATUS VOR DESEL>
1L
2L
3L
4L
5L
6L
1R
2R
3R
4R
5R
6R
VOR/DM
E
STATUS 1/1
SOURCE/ID FREQ RAD/DME
VOR
YJN 115.80 260°
DME YJN 115.80 130
NM
POSITION
N45° 00.00
W072° 00.00
<NAV STATUS VOR DESEL>
1L
2L
3L
4L
5L
6L
