C. Dual VOR and Dual DME:
VORx ID/FREQ/RAD (1L-Line 3, 2L-Line 5): Displays VOR station identifier, tuning frequency (MHz) and radial
from the station (always in MAG). The fields are blanked when the FMS is unable to find the requested station
(e.g. invalid bearing) or when the value of the frequency is changed and the FMS is searching for the new
station identifier. The frequency and radial are values received from the radio interface.
Summary of VORx / Radial Display Layout:
Display
Return
Freq OK Feq NCD Freq FAIL Rad-ial OK Radial NCD Radial FAIL Invalid
Feed back
Nav Freq
Small
white
Blank **** N/A N/A N/A Small white
Radial
N/A N/A N/A Small white Blank **** Small white
DMEx ID/FREQ/DME Slant range (1L-Line 4, 2L- Line 6): Display of DME station identifier, tuned frequency
(MHz) and slant range from the station (always in nautical mile). The fields are blanked when the FMS is unable
to find the requested station (e.g. invalid distance) or when the value of the frequency is changed and the FMS
is searching for the new station ident. The frequency and slant range are values received from the radio
interface
Summary of DMEx / Range Display Layout:
Display
Return
Freq OK
Range OK
Freq NCD
Range All
Freq
FAIL
Range All
Freq OK Range
NCD
Freq OK
Range FAIL
Invalid Feed-
back
DME
Freq
Small white Blank **** Small white Small white Small white
Range
Small white **** **** Blank **** Small white
NAV STATUS [6L]: Returns to NAV STATUS INDEX 1/1 page.
POSITION (5R): Displays position LATITUDE and LONGITUDE or UTM.
VOR DESEL[6L]: Access to VHF NAV DESELECT 1/1 page.
VOR/DM
STATUS 1/1
SOURCE/ID FREQ RAD/DME
VOR1
YJN 115.80 260°
DME YJN 115.80 130
NM
VOR2 YUL 116.30 180°
DME IABC 109.30 12.0
NM
POSITION
N45°00.00
W072°00.00
<NAV STATUS VOR DESEL>
