CMA-9000 FLIGHT MANAGEMENT SYSTEM
C. The sub-mode in [1L] has been selected.
1R
2R
3R
4R
5R
6R
MO
D
DES SCHED 1/1
SPD SCHED
MIN FUEL
<ERASE CRUISE>
1L
2L
3L
4L
5L
6L
TITLE: The title displays:
• “ACT” if descent is active
• “MOD” if the EXEC key is illuminated
• Blanks if descent is not active
followed by DES SCHED
XXX XXX [1L]: Displays the first descent speed sub-mode defined in the policy file. A selected sub-mode is
displayed in large font.
When the prompt is displayed, pressing the adjacent LSK has the following effect:
• The sub-mode's speed schedule is copied into the DES page data field at LSK 2L;
• The sub-mode's name is copied into the DES page title field at LSK 2L with "SPD" appended to the end of
the name if it is less than 6 characters in length. An abbreviated sub-mode name is provided in all other
cases (e.g. MIN FUEL will be displayed as MFUEL SPD);
The font will change from large to small when another descent speed sub-mode is selected or a manual speed
entry is made in LSK 2L on the DES page.
NOTE(S):
• The field title (e.g. “MIN FUEL”) is copied “as-is” from the policy file.
• The field title (e.g. “MIN FUEL”) is copied “as-is” from the policy file.
ERASE [6L]:
“ERASE” is only displayed when an active flight plan modification is in progress. Pressing this key will undo all
changes to the active flight plan and return to the ACT Route status.
DESCENT [6R]: Enables direct access to the VNAV DES page.
