OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
APPR 4/5
This page applies only to the selected approach of the active route. It is used to select and display data
pertaining to the selected approach.
Display the APPR 4/5 page by pressing:
[VNAV] (When in Approach mode) or
[VNAV] [PREV] (When Go-Around mode is active) or
[VNAV] [NEXT] [NEXT] [NEXT] (When in Climb mode) or
[VNAV] [NEXT] [NEXT] (When in Cruise mode) or
[VNAV] [NEXT] (When in Descent mode) or
<APPROACH> from PROFILE page
A. The NDB24L approach has been selected and the approach mode is not active.
B. The NDB24L approach has been selected and the approach mode is active. The airplane just sequenced
the FAF.
1R
2R
3R
4R
5R
NDB24L APPR 4/5
MIN BARO AT RWY24MAP
700 FT 145/ 700A
V_E/D TO RWY24MAP
160KT 2022.1z/25.3NM
HEADWIND CROSSWIND
30KT R5KT
XTK
L0.03
NM
RNP/ANP
1.00/0.05
NM
<APPR REF PROFILE>
1L
2L
3L
4L
5L
6L
6R
ACT NDB24L APPR 4/5
MIN BARO AT RWY24MAP
700 FT 145/ 700A
1L
1R
V_E/D TO RWY24MAP
160KT 2022.1z/25.3NM
HEADWIND CROSSWIND
3 KT R18KT
XTK VDEV
L0.03
NM 273
RNP/ANP
2R
3R
4R
5R
6R
1.00/0.05NM
<APPR REF PROFILE>
2L
3L
4L
5L
6L
