OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
ALTITUDE CONSTRAINTS/RESTRICTIONS/CROSSING ALTITUDES [1R] to [5R]: The FMS displays the
waypoint altitude constraints or crossing altitudes as follows:
NOTE: Missed approach waypoints have no crossing altitude or speeds displayed.
Altitude
Constraint
Display Font
Crossing
Altitude Display
Font
Waypoint Type
Waypoint with a
Navigation
Database
defined Altitude
Constraint
Waypoint with a
Pilot-entered
Altitude
Constraint
Waypoint with
no Altitude
Constraint
Applicable VNAV
mode
Achievable Altitude
Constraint/Crossing
Altitude
small font green large font green small font white Climb/Cruise/Descent
/Approach
Altitude
Constraints/Crossing
Altitudes that cause
an unachievable path
small font yellow large font yellow small font white Climb/Cruise/Descent
/Approach
Temperature-
Compensated
Waypoint
small font
reverse video
green
small font
reverse video
green
small font
reverse video
white
Descent/Approach
Temperature-
Compensated
Altitude Constraints
that cause an
unachievable path
small font
reverse video
yellow
small font
reverse video
yellow
N/A Descent/Approach
Page RRJ-A-49
August 17, 2010
