Section 5: The Patchbay
Euphonix CS3000/2000 Operation Manual 5 - 11
Master Patch Unit
User Connections
Front
12
L (A) R
ST1 Out
L (B) R
(Ins. Send)
L (C) R
Mon A Out
L R
Mon B Out
L R
L (C) R
TB
IN
3 4 5 6 7 8 9 101112131415161718192021222324252627282930313233343536373839404142434445464748
L (A) R
ST2 Out
L (B) R
(Ins. Send)
L (C) R
Mon C Out
L R
TB
OUT
MULT A
MULT B
(Ins Rtn)
L (C) R
(Ins Rtn)
L (C) R
Ext 2 In
L (B) R
L
(A)
R
Ext 1 In
L (B) R
L (C) R
L (A)
R
A1 A2 A3 A4 A5 A6 A7 A8
AUX BUS OUT
49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 969588 89 90 91 92 93 94
(A)
Zinc
Gold
TO AUDIO MAINFRAME
USER MON A,B,C TB
USER ST2
USER ST1 USER AUX 1 - 8 USER EXT1/EXT2
EUPHONIX P/N 950-01097 MASTER PATCHBAY
CHASSIS GND
JACK GND
Stereo
Monitor Out
ST1 Bus Out ST2 Bus Out
External
Stereo Inputs
Aux Bus Out
Rear
There is one Master patch unit per console, and it carries all the main inputs
and outputs from the Master Audio Module. As with the Channel patch unit it
has two rows of 48 jacks and is connected to the Audio Tower via one 90-pin
Elco snake. All the inputs and outputs to the external studio equipment are
connected to the unit through 38-pin Elco connectors.
As with the Channel unit, the upper jacks are console outputs and lower jacks
are console inputs; signal flow in the patchbay is from top to bottom. All the
upper jacks are half-normalled to the lower jacks.
The 90-way Elco at the far left is the Tower interface. The remaining 5 Elco 38
connectors are the user interface. The pinout diagrams can be found in the
Service Manual.
Note that the Master patchbay labels have blank areas for user label-
ling. These are for the user-definable inputs and outputs to the Master
audio section. Following is a diagram that shows the user inputs and
outputs for a standard Master patch unit. The Channel patch unit also
has user-definable ins and outs.
12
L (A) R
ST1 Out
L (B) R
(Ins. Send)
L (C) R
Mon A Out
L R
Mon B Out
L R
L (C) R
TB
IN
3 4 5 6 7 8 9 101112131415161718192021222324252627282930313233343536373839404142434445464748
L (A) R
ST2 Out
L (B) R
(Ins. Send)
L (C) R
Mon C Out
L R
TB
OUT
MULT A
MULT B
(Ins Rtn)
L (C) R
(Ins Rtn)
L (C) R
Ext 2 In
L (B) R
L
(A)
R
Ext 1 In
L (B) R
L (C) R
L (A)
R
A1 A2 A3 A4 A5 A6 A7 A8
AUX BUS OUT
49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 969588 89 90 91 92 93 94
(A)
User-Definable Inputs
User-Definable Outputs
Audio destinations —>
<— Audio sources
