Section 9: Dynamics
Euphonix CS3000/2000 Operation Manual 9 - 7
The ES108A Rear Panel
I
0
MIDIMETER
VOLTS AMPS FUSE
100/120
220/240
1.0 2A
1A
0.5
50-60Hz 110 WATTS
USE SLO-BLO FUSE
IN OUT
IN OUT/THRU
Made in U.S.A.
120
Ch 1-8
INPUT
Ch 1-8
EXT KEY
Ch 1-8
OUTPUT
NOTE: The Output and Ext Key input Elcos have changed locations on the back
panel with the release of the ES108A. Please note this if installing an ES108A
in a rack of ES108s. The Serial Number tag has now been moved to the left
side panel near the power switch (if looking at the unit from the rear) to
accomodate additional enclosure vents.
