CS3000 Side View and Footprint
Appendix 6: CS3000 Mix Controller Dimensions
CS3000
Top View
Front
Dimension A
Dimension B
2.25"
58mm
8.18"
208mm
34.77"
883mm
4.25" x 8.5"
108 x 216mm
Leg Opening
CS3000-2
CS3000-3
CS3000-4
57.4 1455
81.3 2065
105.3 2674
Frame Model #
Dimension A
inches mm
Dimension B
inches mm
48.9 1242
72.8 1849
96.8 2459
Dimension C
Dimension C
inches mm
48.2 1223
72.1 1830
96.1 2440
Figure 2 - CS3000 Mix Controller Dimensions
38.5"
978mm
34.8"
883mm
13.9"
351mm
23.8"
605mm
1.9"
47mm
29"
737mm
3.9"
99mm
4.5"
114mm
1.0"
25.4mm
7.7"
196mm
23.8"
605mm
15.0"
381mm
