Section 3: SnapShot Recall
3 - 10 Euphonix CS3000/2000 Operation Manual
The same nulling laws apply to rotary controls as faders, although the red
indicator does not show the direction of the null point. When the control
passes through the null point the red LED goes out and the rotary control is
now active.
Each time you recall a SnapShot, it is not necessary to null every control. You
will instantly hear the recalled settings. Null a control only if you need to
modify an audio level.
!!CAUTION!! When in the SnapShot Mode, pressing the Default key in Page
4 of the DSC Assignable Keys (see diagram bottom of page) or pressing the
M1 assignment key on the Master Control Panel will allow you to zero the
desk. It will deselect all routing and turn down every gain control. Try this to
see the effect. Many of the controls will show a red indication since their
physical position will now be different from the actual audio settings.
!!EXTRA CAUTION!! When in the SnapShot menu, pressing [Clr] followed by
[F3] will allow you to completely clear the SnapShot memory. It will not reset
the desk, so all of your current routing and levels will remain intact. This can
be useful if you want to create a new title, clear out the SnapShot memory
and store the current desk settings as the first SnapShot.
In both cases, as a precaution against totally destroying a good mix, the
SmartDisplay will ask if you are sure you want to do this. You need to confirm
by pressing [F3] (Yes). If you wish to abort, press [F4] ([No]) or press [Esc].
F3F1 F2 F4
A simple way to make the audio level match the current physical position of
the controls and faders is to press the Assignable Key labelled “Physical” in
page 4 when in SnapShot mode. Instantly, all null indicators go out indicating
that the audio levels now match the position of the controls. This can also be
done from the Master Control Panel. Press the ST* button in the Master
Control Panel keypad.
Zeroing the Desk
CLEAR All
SnapShot
Memories
Match Current
Position
**SS= Sure? Yes [No]
PAN BAL
*
ST
-
DIR
+
Bus
Match
Master Control
Panel keypad
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Faders
Mon
Select
Snap
Shot
Preset Macro
Pg 1 Pg 2 Pg 3 Pg 4
Store
Mon
Cnfg
Studio
Faders
Pg 1 Pg 2 Pg 3 Pg 4
Store
Mon
Select
Snap
Shot
Preset Macro Mon
Cnfg
Studio
49
50
DEFAULT
PHYSICAL
AUTONULL
Recall Default
(Zero) SnapShot
Toggle Auto/Manual
Null Mode
Match levels
to Controls
DSC Assignable
Keys Section
