Section 9: Dynamics
9 - 34 Euphonix CS3000/2000 Operation Manual
Page 1 Numeric Keypad
Select Compressor/Gate
Below is the DSC Numeric keypad mapping for compressor and gate param-
eters and the available range for each parameter. Note that the available
range of some parameters is sometimes dependent on where other param-
eters are set (e.g., the range of possible values for Compression Knee can be
affected by the Threshold setting).
Page 1 Parameters
Keypad # Parameter Options or value range Type
0 Gate Depth -80 dB to 0 dB Rotary
Enter Gate Threshold -40 dB to +10 dB Rotary
Del Input Level -6 dB, 0 dB, +6 dB, +12 dB Switch
1 Gate Attack 10 µs to 1 s Rotary
2 Gate Release 2 ms to 4 s Rotary
3 Gate Hold 2 ms to 2 s Rotary
4 Compression Ratio 1:1 to ∞:1 to -1:1 Rotary
5 Compression Threshold -40 dB to 20 dB Rotary
6 Compression Knee 0 dB to 30 dB Rotary
7 Compression Attack 100 µs to 1 s Rotary
8 Compression Release 1 ms to 10 s Rotary
9 Compression Makeup Gain 0 dB to 24 dB Rotary
L1 Filters In or Out Switch
L2 Gate In or Out Switch
L3 Compressor In or Out Switch
L4 Dynamics Processor In or Out Switch
+/– Dynamics Page # Page 1 or Page 2 Switch
789
456
123
0 Enter Del
Compressor
Gate
Release
Makeup Gain
Ratio
Attack
Release
Hold Time
Threshold
Knee
Attack
ThresholdDepth Input Level
(Main Input and Side Chain)
