A - 12 Euphonix CS3000/2000 Operation Manual
▼ Universal Balanced transformerless input
Input Input Impedance = 2.3kΩ
Amplifiers Gain = +64 to 0dB in 0.5dB steps
(Mic or Line) Input Noise = -124dBu equiv. @ +64dB gain, 150Ω src.
Frequency Response = 15Hz to 30kHz, +0.10/-0.25dB
Maximum Input Level = +28dBu
CMRR 50dB typical 20-20kHz
Phantom Power = +48Vdc, individually selectable
High Pass Filter = fixed 100Hz, 18dB/octave
▼ Line Inputs Balanced transformerless input
Input Impedance > 10kohms
Optimum Input Level = +4dBu from < 1 kohms
Input Noise = -95dB
Frequency Response = 15Hz to 30kHz, +0.1/-0.25dB
Maximum Input Level = +28dBu
CMRR 50dB typical 20-20kHz
▼ Outputs Balanced and floating transformerless output
Output Impedance = 50 ohms
Nominal Output Level = +4 dBu
Max Output Level = +27.5 dBu into > 600 ohms balanced
▼ Equalizer 4-band programmable parametric
Enhanced state-variable design, symmetrical boost/cut
Hi shelving, 1.32kHz to 21.1kHz, +/- 15dB
Hi mid, 659Hz to 21.1kHz, +/- 15dB, Q from 0.32 to 11.6
Lo mid, 41.2Hz to 1.32kHz,+/- 15dB, Q from 0.32 to 11.6
Lo shelving, 20.6Hz to 330Hz, +/- 15dB
Accuracy better than +/- 0.5dB from displayed curve
(gains adjusted in 0.5dB steps, frequencies in 1/12 octave
steps, Q ‘s in 16 steps)
▼ Fader/Aux Send Gain = +6dB to -66dB
DCA's Resolution = 4096 linear steps
Noise = 90dB below nominal input
Frequency Response = 15Hz to 30kHz, +0.1/-0.25dB
Distortion < 0.003% THD+N, < 0.003% IMD (SMPTE)
Precision = 0.01dB repeatability
Step Noise < 80dB rms below nominal input
▼ Oscillator Programmable internal sine wave generator
Frequency Range = 20.6Hz to 21.1kHz in 1/12 octave steps
Preset Frequencies = 100Hz, 1kHz, 10kHz
Level Range = +/- 20dB in 0.5dB steps
Distortion < 0.003% THD+N
CONSOLE SPECIFICATIONS
▼ Noise Floor Line Input to Direct Output < -90dB @ unity gain
Line Input to Mix Output < -90dB @ unity gain
24 Line Inputs to Mix Output < -80dB @ unity gain
▼ Headroom +24dB above internal 0dB at all times
▼ Dynamic Range Max Signal to Noise Ratio >110dB (Line In to Mix Out)
▼ Distortion Mic/Line In to Direct Out < 0.005% THD+N
IMD (SMPTE) +10dBu output
Mic/Line In to Mix Out < 0.005% THD+N
IMD (SMPTE) +10dBu output
▼ Frequency Mic/Line Input to Dir Output = 15Hz to 30kHz, +0/- 0.4dB
Response Mic/Line Input to Mix Output = 15Hz to 30kHz, +0/- 0.4dB
▼ Crosstalk Channel to Channel < -90dB @ 1kHz
Mix Buses < -90dB @ 1kHz (-80 dB @ 10kHz)
▼ Fader Muting > 90dB @ 10kHz
▼ Clip +10dB to +24dB headroom warning adjustable in 1 dB steps.
Indication Detected pre/post all console mic preamps, sends & faders.
▼ Maximum +76dB from Mic Input to Mix Output
Gain
▼ Meters Programmable range from 60dB or 39dB / Peak or RMS,
+/- 0.3dB accuracy within +/- 12dB of unity gain
▼ Dynamic All console functions recorded with frame accuracy
Automation Internal SMPTE time-code reader (all formats)
▼ Snapshot SnapShot store/recall entire console < 1/30th second
Recall
▼ Notes +4dBu = nominal line input/output level (0VU internal)
0 dBu = 0.775Vrms @ any impedance
THD+N measured @ 1kHz, 22Hz to 30kHz bandwidth
Noise measurements are unweighted, 22Hz - 22kHz
bandwidth.
Design and specifications are subject to change without
notice.
OVERALL SYSTEM INFORMATION
▼ Configurations CS3000/2000 Model # is frame size followed by # of faders.
Three frame sizes available which are able to accomodate
the following # of faders with a DSC:
40 40 Mics, 40 Eqs, 80 Line Inputs (24 MT buses)
72 72 Mics, 72 Eqs, 144 Line Inputs (24 MT buses)
104 104 Mics, 104 Eqs, 104 Line Inputs (24 MT buses)
Standard features include: 2 stereo (4 mono) mix buses, 8
aux buses, 3 stereo monitor feeds, up to 3 programmable
effect loops per channel. Stereo PFL/AFL.
▼ Patchbay 24 jacks per channel, 96-jack master section, Elco/EDAC
multipin cables from Audio Tower to Mix Controller.
Standard cable length 10m (32ft).
Two patchbay layouts available:
Standard Euphonix patchbay with one 19” connectorized
patch unit (96 jacks) per 8 faders (4 channels) plus a master
patch unit (96 jacks). TT/Bantam jacks.
System is fully connectorized and can be supplied without a
patchbay.
▼ Control 48 twisted/shielded pair multipin (Elco/EDAC)
Cable 2.0 MHz parallel data transmission
Standard cable length (minimum) 10m (32ft).
▼ Version 2 Pentium/133 with 32MB RAM, 1.7GB internal hard disk,
MixView 3.5” floppy disk drive, Iomega Jaz 1GB removable cartridge
Platform drive, compact keyboard, mouse. Flat screen TFT Active
Matrix screen with DSC.
▼ Power Audio Tower: 4 voltage ranges available. Not switchable.
Voltage must be within +/- 6% of recommended spec.
Audio Cube: 4 voltage ranges available. Not switchable.
Mix Controller: 110 - 125 VAC, 8.6 amps (standard outlet)
(Audio Tower and Mix Controller are opto-isolated)
Mix Controller, ES108, & computers can be switched for
other voltage requirements.
Service required for Audio Tower: 30 amp @ 110 Vac
Service required for Audio Cube: 30 amp @ 110 Vac
▼ Dimensions Audio Tower: H 50.70” (1345mm) x W 17.40” (442mm) x
D 19.00” (483mm). May be 19” rack mounted.
Mix Controller CS3000: D 34.8” (883mm). H @ palmrest =
29.00” (737mm), @ meter bridge = 38.50” (978mm)
▼ Mix Controller CS3000-2 57.4” (1455mm)
Width CS3000-3 81.3” (2065mm)
CS3000-4 105.3” (2674mm)
Appendix 10: CS3000/2000 Technical Specifications
