Hard disk drives / solid state drives
I For numbering SAS backplanes see section "2.5-inch HDD backplane
overview" on page 139.
Cable Cabling list no. from to
SAS cableT26139-
Y4040-V4
C42
SAS expander board
connector X1
SAS backplane 1
connector X1
SAS cable
T26139-Y4040-V4
C42
SAS expander board
connector X2
SAS backplane 2
connector X1
SAS cable
T26139-Y4040-V6
C43
SAS expander board
connector X3
SAS backplane 3
connector X1
SAS cable
T26139-Y4040-V6
C43
SAS expander board
connector X4
SAS backplane 4
connector X1
SAS cable
T26139-Y3963-V102
C44
SAS expander board
connector X5
SAS backplane 5
connector X1
SAS cable
T26139-Y3963-V102
C44
SAS expander board
connector X6
SAS backplane 6
connector X1
SAS cable
T26139-Y3963-V103
C20
SAS controller
connector MLC1
SAS expander board
connector MLC1
SAS cable
T26139-Y3963-V103
C20
SAS controller
connector MLC2
SAS expander board
connector MLC2
HDD power cable
T26139-Y4030-V102
C1
Power backplane
connector X21
SAS backplane 1
connector X6
SAS backplane 2
connector X6
SAS backplane 3
connector X6
SAS backplane 4
connector X6
HDD box power
cable
T26139-Y3939-V402
C6
System board
connector P5
SAS backplane 5
connector X6
SAS backplane 6
connector X6
SAS expander board
connector X20
