Beginning an Exam
LOGIQ 7 Basic User Manual 4-21
Direction 2392206-100 Rev. 1
Changing Patient Information or an Exam (continued)
4. To have the database shown in its entirety, Backspace on
the Search string and all patient names appear.
5. Press Register to register the new exam.
A new exam is automatically created on that patient unless
an exam already exists on that day for that patient.
If an exam already exists for that patient, the following
warning is displayed.
Figure 4-17. Dialog Box
Select “Yes“ to reuse the existing data.
Select “No” to create a new exam for the patient.
6. To display the patient information on the title bar, press the
Esc key or the B-Mode key.
Select the Preset and appropriate probe Touch Panel keys,
if necessary.
