Mode Measurements
LOGIQ 7 Basic User Manual 7-55
Direction 2392206-100 Rev. 1
Distance measurement (continued)
The following hints can help you to perform distance
measurements:
HINTS
• Before
you complete a measurement:
• To toggle between active calipers, press Measure.
• To erase the second caliper and the current data
measured and start the measurement again, press
Clear once.
• After
you complete the measurement:
• To rotate through and activate previously fixed calipers,
adjust Cursor Select.
• To erase all data that has been measured to this point,
but not data entered onto worksheets, press Clear.
