Generic Measurements
LOGIQ 7 Basic User Manual 7-77
Direction 2392206-100 Rev. 1
Volume (continued)
To make a volume calculation using one ellipse:
1. Select Volume.
2. Make one ellipse measurement.
3. Select Volume.
The system displays the ellipse measurement and the
volume in the Results Window.
To make a volume calculation using one ellipse and one
distance:
1. Select Volume.
2. Make one distance measurement and one ellipse
measurement.
3. Select Volume.
The system displays the distance and ellipse measurement
and the volume in the Results Window.
Calculation formulas are available in the ADVANCED-
REFERENCE-MANUAL.
HINTS
• Volumes are most accurate when measurements are taken
in the sagittal and axial scan planes.
• To display sagittal and axial plane images simultaneously,
use the side-by-side dual format option.
