OB Measurements and Calculations
LOGIQ 7 Basic User Manual 9-29
Direction 2392206-100 Rev. 1
Humerus Length
To measure humerus length, make one distance measurement:
1. Select HL; an active caliper displays.
2. To position the active caliper at the start point, move the
Trackball.
3. To fix the start point, press Set.
The system fixes the first caliper and displays a second
active caliper.
4. To position the second active caliper at the end point, move
the Trackball.
A dotted line connects the measurement points.
5. To complete the measurement, press Set.
The system displays the humerus length in the Results
Window.
Spinal Length (SL)
To measure spinal length, make one distance measurement:
1. Select SL; an active caliper displays.
2. To position the active caliper at the start point, move the
Trackball.
3. To fix the start point, press Set.
The system fixes the first caliper and displays a second
active caliper.
4. To position the second active caliper at the end point, move
the Trackball.
A dotted line connects the measurement points.
5. To complete the measurement, press Set.
The system displays the spinal length in the Results
Window.
USA
Europe
Tokyo
Osaka
ASUM
USA
Europe
Tokyo
Osaka
ASUM
