GE LOGIQ 7 Basic User Manual

OB Measurements and Calculations
LOGIQ 7 Basic User Manual 9-33
Direction 2392206-100 Rev. 1
Tibia Length
To measure tibia length, make one distance measurement:
1. Select Tibia; an active caliper displays.
2. To position the active caliper at the start point, move the
Trackball.
3. To fix the start point, press Set.
The system fixes the first caliper and displays a second
active caliper.
4. To position the second active caliper at the end point, move
the Trackball.
A dotted line connects the measurement points.
5. To complete the measurement, press Set.
The system displays the tibia length in the Results Window.
Ulna Length
To measure ulna length, make one distance measurement:
1. Select Ulna; an active caliper displays.
2. To position the active caliper at the start point, move the
Trackball.
3. To fix the start point, press Set.
The system fixes the first caliper and displays a second
active caliper.
4. To position the second active caliper at the end point, move
the Trackball.
A dotted line connects the measurement points.
5. To complete the measurement, press Set.
The system displays the ulna length in the Results Window.
Volume
See ‘Volume’ for more information.
USA
Europe
Tokyo
Osaka ASUM
USA
Europe
Tokyo
Osaka ASUM
