Anatomical Survey
LOGIQ 7 Basic User Manual 9-45
Direction 2392206-100 Rev. 1
Editing
• To activate the Anatomical Survey, select Anatomy on the
OB Worksheet Touch Panel.
Figure 9-5. OB Worksheet Touch Panel
• Fill the required field.
Table 9-3: Anatomical Survey
Field Description
Fetus Pos Indicate the fetal position within the uterus.
PLAC Identify the location of the placenta.
ANATOMY Enter the following information for each part of the
anatomy imaged:
1. Imaged? : Check the box that you did image this part
of the anatomy.
2. Appearance : If you checked the Imaged? box,
indicate whether the appearance was normal or
abnormal.
You can add the required anatomy up to 9 additional
anatomy.
Move the Trackball to the blank field.
Enter the anatomy name.
