Cardiology
10-108 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Selection of
Images from a
group
If groups of images have been defined in the protocol template,
you can select a group of images for analysis and sequentially
analyze all images from all groups from within the Analysis
screen.
1. In a stress examination, press Protocol. A preview of the
acquisition displays.
2. Use the Trackball to move the cursor to the group in the
Group list. The frame of the images belonging to the group
are highlighted.
3. Press Set to open the images in the Analysis screen.
Figure 10-19. Template Screen
1 Select and open an image group
2 Select a projection
3 Select an image
