Console Overview
LOGIQ 7 Basic User Manual 3-13
Direction 2392206-100 Rev. 1
Front Panel
Located on the front panel are Microphone, LED, and Reset.
Figure 3-7. Front Panel
1. Microphone 3. Serial
2. LED (HD access) 4. Reset
Serial
2
1
4
3
