Configuring Connectivity
LOGIQ 7 Basic User Manual 16-89
Direction 2392206-100 Rev. 1
Echo Database V3.0
Figure 16-62. Echo Database V3.0 Service
Table 16-53: EchoDatabase ODBC
Preset Parameter Description
Image Path Enter the path to the image archive. If the image
archive is on a removable disk, select Removable
Media.
Image Path Name Type the path’s name.
Report Enter the path to the report archive. If the report
archive is on a removable disk, select Removable
Media.
Image Path/Report
Path: Removable
Media
Select media.
Database SQL.INI The name of the database.
